CP/DC Core Platform/Drop Cables
Features
- FTTH Drop Cables for aerial, duct, and direct burial
- Compatible with SuperTap, OptiTap, and OptiTip connectors
- Peelable jacket for easy stripping
- Contractors familiar with cables and processes
Cable Types
Flat Drop Dielectric/7mm Toneable/9.8mm
Round Dielectric/5mm Toneable/7.8mm
Fiber count 1-24
Fiber types G.657.A1/A2, G652.D
SC/APC typical IL <=0.15dB RL >=65dB
MPO Performance IL<=0.30 RL>=50dB
Attenuation 1310nm/0.36 1550nm/0.22
Jacket material PE Black
Loose tube fiber diameter 250um
Tight buffer 900um/3mm PVC tube white
Strength member FRP
Operating temperature -40 to +70C
Telcordia GR 20 OSP
Cable tensile load Install 300lbs, long term 90lbs
